DRAWING OILS- PRODRAW SERIES

  • “Simply Precision in drawing”
Images

DRAWING OILS- PRODRAW SERIES

Kouper specializes in manufacturing of wire drawing oils. We have highly advanced range of products specifically geared for the copper & aluminum wire drawing industry.

Kouper lubricants offers comprehensive lubricant solution to the wire drawing industry in wire and tube manufacturing

  • Rod breakdown (RBD)
  • Intermediate drawing.
  • Fine-wire drawing & Extra fine wire drawing.
  • Drawing of Single and multi-wire systems down to smallest diameters of 0.20 mm

KOUPER offers a wide range of Neat and water-soluble lubricants for all different categories of alloys like copper, aluminum and stainless-steel.

Kouper Wire drawing lubricants will be a better option for all alloy options given below

  • Copper wire & tube drawing oils
  • Aluminium wire & tube drawing oils
  • MS & steel wire drawing oils

    Copper Wire & Tube Drawing Oils
  • KOUPER PRODRAW CU 160

    KOUPER PRODRAW CU 160 is a high performing semi synthetic copper wire drawing oil for Rod breakdown, intermediate and fine wire drawing.

    PRODUCT KOUPER PRODRAW CU 160
    Application
    • Rod wire drawing
    • Medium & Fine wire drawing
    • Single and multi-wire systems down to smallest diameters of 0.20 mm
    Material Universal. Steel, cast iron, Stainless Steel, Suitable for Aluminium & sensitive alloys,
    Emulsion pH (5%) 9.0-9.4
    Emulsion Corrosion protection 3% (Note) 1.1
    Refractor meter index 1.1
    Appearance Brown
  • KOUPER PRODRAW CU 111

    KOUPER PRODRAW CU 111 is a high performing semi synthetic copper wire drawing oil, specifically formulated for precision drawing on single and multi-wire systems. It is used for drawing of blank, tin, and silver-plated copper wire up to final diameters of 0.10 mm.

    PRODUCT KOUPER PRODRAW CU 111
    Application
    • Medium & Fine wire drawing
    • Single and multi-wire systems down to smallest diameters of 0.10 mm
    • Drawing of blank, tin, silver plated & enameling copper wires
    Material Copper & Copper alloys
    Emulsion pH (5%) 9.0-9.4
    Refractor meter index 1.1
    Appearance Brown
    • Aluminium Wire & Tube Drawing Oils
  • KOUPER PRODRAW AL 200

    KOUPER PRODRAW AL 200 is a non-water miscible specialty wire drawing fluid for the continuous wet drawing of Aluminium rod and its alloys.

    PRODUCT KOUPER PRODRAW AL 200
    Application
    • Rod breakdown (RBD)
    • Intermediate drawing.
    • Medium wire drawing
    • Fine-wire drawing
    Material Aluminum & Aluminum alloys
    K. Viscosity at 40 °C [mm²/s] 160-180
    Flash point [°C] ≥ 270
  • KOUPER PRODRAW AL 100

    KOUPER PRODRAW AL 100is a non-water miscible specialty wire drawing fluid for the for medium and fine drawing of Aluminium and Aluminium alloys.

    PRODUCT KOUPER PRODRAW AL 100
    Application
    • Medium wire drawing
    • Fine-wire drawing
    Material Aluminum & Aluminum alloys
    K. Viscosity at 40 °C [mm²/s] 20-25
    Flash point [°C] ≥ 170
    • Steel & Mild Steel Wire Drawing Oils
  • KOUPER PRODRAW ST 146

    KOUPER PRODRAW ST 146 is a non-water miscible drawing oil designed for wet cold drawing process of both low and high alloy steel.

    PRODUCT KOUPER PRODRAW ST 146
    Application
    • Rod breakdown (RBD).
    • Intermediate drawing.
    • Drawing of profiles (Round, square, hexagon & Octagon) with difficult geometries.
    • Drawing of Seamless tubes.
    • Sheet forming
    Material Steel & Stainless Steel
    K. Viscosity at 40 °C [mm²/s] 300-330
    Flash point [°C] ≥ 190
  • KOUPER PRODRAW ST 020

    KOUPER PRODRAW ST 020 is a non-water miscible wire drawing oil, specifically formulated for the medium and fine wire drawing of steel and stainless-steel wires.

    PRODUCT KOUPER PRODRAW ST 146
    Application
    • Medium wire drawing
    • Fine-wire drawing
    Material Steel & Stainless Steel
    K. Viscosity at 40 °C [mm²/s] 20-25
    Flash point [°C] ≥ 160
